Meltblown Machine Meltblown Nonwoven Fabric Production Line
Product description:
This equipment is used for the production of melt-blown non-woven fabrics. Using polypropylene as the main raw material, supplemented with master batch and additives such as anti-oxidation, static electret, flame retardant, etc., it produces melt-blown nonwoven fabrics with different colors and different functions.
The products are widely used in industrial felt, industrial oil-absorbing cloth, industrial sound insulation cotton, industrial high-efficiency filter materials, etc. At the same time, this production line can also produce melt-blown fabric for masks.
Technical Parameter:
| No | Item | Technical Parameter |
| 1 | Power supply | 380V/50HZ |
| 2 | Installation power | 300 KW |
| 3 | Capacity | 300-500 kg/24 h |
| 4 | Line Dimension | 15000*5000*4500 mm |
| 5 | Raw material | PP melt-blown flake ,color master batch,etc |
| 6 | Melt index of PP melt-blown flake | 1200~1800±100g/10min |
| 7 | Melt-blown flake requirement | <250ppm; Monofilament fineness: 2um-5um |
| 8 | Melt-blown flake moisture | <0.2% |
| 9 | Melt-brown fiber diameter | 1-6um |
| 10 | Final product width | 600mm |
| 11 | Max winding diameter | Max.500mm |
| 12 | Line speed | 10-30m/min |
Standard process:
Polymer preparation → Melt extrusion → Metering pump → Melt-blown die head assembly → Melt flow stretching → Cooling → Coiler
Our services:
♦ Help you choose the most suitbal machine.
♦ Making the machine according to you request.
♦ Give you machine's details for help you use machine more better.
♦ One year warranty.
♦ Competitive price for all our machines to meet customer demand.
♦ World wide after services .
