200G/M2 highway moisture-proof non-woven geotextile engineering geotextile

200g/m2 Nonwoven Geotextile Engineering Geotextile for Highway MoistureDescriptionMade from 100%Virgin PET(Polyester) or PP(Polypropylene) short fiber by nonwoven needle punched  manufacturing process.tbric.weight per square meter :100g/m2-1100g/m2Width:1.0m-6.0mLength:50m 100m or customedFeatures1.Good creep property and&n

Featured Products

200g/m2 Nonwoven Geotextile Engineering Geotextile for Highway Moisture
Description
Made from 100%Virgin PET(Polyester) or PP(Polypropylene) short fiber by nonwoven needle punched  manufacturing process.tbric.
weight per square meter :100g/m2-1100g/m2

Width:1.0m-6.0m
Length:50m 100m or customed


200G/M2 Nonwoven Geotextile Engineering Geotextile for Highway Moisture

Features

1.Good creep property and hydraulics property
2.Anti-corrosion
3.Excellent anti-aging

4.Resistangt to acids and alkalis
It has Isolation,filtration,drainage,reinforcement,protection and maintenance,etc
200G/M2 Nonwoven Geotextile Engineering Geotextile for Highway Moisture

Application and Our projects


Hydraulic Projects: River bank, Dam, Coastal beach, Coast
Separation and reinforcement in road and railway construction

Cushioning and protection in many containment projects
200G/M2 Nonwoven Geotextile Engineering Geotextile for Highway Moisture


Packaging & Shipping
The nonwoven geotextile shall be roll onto a substantial core, clearly labeled and enclosed in woven bag. Packing must be adequate for safe transportation to the point of delivery

The label should include manufacturer, style, lot and/or roll number, weight, length, and width.

200G/M2 Nonwoven Geotextile Engineering Geotextile for Highway Moisture


Installation
Upon request by the customer, we could offer a full turnkey installation service.
We can also provide paving video if you want to paving yourself.


Specification Parameter

Filament spunbonded Nonwoven geotextile (GB/T17638-2017)
ProperticsTest Value
100g/m2150g/m2200g/m2300g/m2400g/m2500g/m2600g/m2700g/m2800g/m2
The Fracture Strength (KN/m)3.05.08.010.015.020.025.030.040.0
   Longitudinal and Transverse Break strength (KN/m)3.05.08.010.015.020.025.030.040.0
   Longitudinal and Transverse   Standard Strength Corresponding  Elongation%20-100
The bursting Strength (CBR)/KN0.61.01.41.82.53.24.05.57.0
Vertical and horizontal Tear Standard/KN 0.100.150.200.250.400.500.650.801.00
Sieve  Size O90( O95)/mm0.07-0.20
Vertical Permeability  cm/s k*(10-1~10-3)    k=1.0-9.9
Company introduction

Our factory were found in 2009. Located in Dezhou city , we covers an area of 34,000sqm ,We are professional manufactory in Geosynthetics. With advanced equipment and strict QC procedures in order to ensure high quality. Guaranteeing stable and timely supply ,credible quality and sincere service ,our products sell well in both domestic and overseas markets. we have exported our products to mang countries and regions all over the world, if you are interested in any of our products, or wish to place a customized order,please contact us , we will our best to meet your needs.


Design
Our factory engineering team can provide solid advice on all types of Seepage control industry , as well as their correct design for projects, including construction details and advice on the general configuration of the project.


Documentation
Each roll of geotextile has its own identification number. The identification number is traceable in line with the
quality control plan.  We can add the necessary documentation or modify the packaging for countries and territories with special product certification requirements.




FAQ

Q: Are you trading company or manufacturer ?
We are factory.
Q:Can you do OEM?
Yes, of course. We can produce the products as your request.
Q: Do you provide samples ? is it free ?
Yes, we could offer the sample for free charge, but the freight will on your account .
Q: How long is your delivery time?
Generally it is 3-5days after we received prepay
Q: What is your terms of payment ?
30% T/T in advance, balance against the copy of B/L


If you have another question, please feel free to contact us at any time.
