High Speed ​​Non Woven Handle Cube Bag Box Bag Cloth Bag No Plastic Bag Shopping Bag Machine

 Product DescriptionUseage: Primary Shaping Non-woven Box Bag Making Machine (ZX-LT500)This machine adopts mechanical, optical, electrical and pneumatic integration technology, suitable for feeding the roll material of non-woven fabric and laminated non-woven fabric. It\'s specialized equipment for making the primary shapin

Featured Products



Product Description

Useage: Primary Shaping Non-woven Box Bag Making Machine (ZX-LT500)

This machine adopts mechanical, optical, electrical and pneumatic integration technology, suitable for feeding the roll material of non-woven fabric and laminated non-woven fabric. It's specialized equipment for making the primary shaping non-woven(laminated) three-dimensional bag. This equipment features stable production, strong and decent sealing of bags, good looking, top grade, fancy and reusable, mainly applied in the field of non-woven wine packing, beverage packing, gift bags, and hotel promotional bags, etc.


Machine Advantage:

1.This machine adopts Taiwan PLC touch screen,which can be edited.
2.Auto counting and stopping when setting numbers freely;
3.High voltage static processor and auto constant temperature heating controller;
4.Equipped with stepping motor(computer fixed length),manual unwinding magnetic powder tension controller and auto rectifying deviation, photoelectric tracking,printing color mark track orientation,auto counting and alarming,auto punching etc.,which make it accurate and stable.
5.All aspect of the bags adopts thermal bonding by ultrasonic welding,such as bag edge folding, side sealing etc, which makes the machine fast and easy to operate , the products firm sealing,beautiful and decent.
With CE certification and ISO9001 certification.High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

Main Technical VARIABLES
Product Parameters

TypeZX-LT500
Material Unwinding Width550-1160MM
Production Speed40-80Pcs/Min
Bag Height200-450mm
Bag Width180-500mm
Width Of Bag Gusset80-200MM
Length Of Bag Handle370-600
Material Basis Weight(Thickness)70-120g/m2
Total Pwer40KW
Air Pressure1.0Mpa
Air Flow1.2M3/Min
Power Supply380V/50HZ
Overall Dimension5000*6000*2600mm
Weight9000Kg
Recommend Other Products

Detailed Photos

High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine
Unwinding Fabric Roll→Side Folding→Handle Sealing→Indentation→Positioning→Cut Off→Bag Shape Forming→Ultrasonic Welding→Bag Collecting→Finished Product
Company Profile



About US:

Zhejiang Zhengxin Machinery Co.,Ltd located in the seashore city of Wenzhou Pingyang.The company is a technology-based enterprise with technical strength and economic power.The main production is automatic non woven bag making machine,non woven fabric printing machine,non woven cross cutting machine,non woven slitting machine and non woven bag handle hot sealing machine etc. Equipment of non woven bag machinery completed.We have a group of middle and senior technical personnel and strong technical force,with design,development,production,installation,service integrity of operating system and passed the ISO9001 quality system certification and CE international safety certification,.

Our Team:
High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

TECHNICIAN IN CUSTOMER FACTORY:
High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

OUTDOOR EXTENDING:
High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

Our Exhibitions:
High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine
Packaging & Shipping

High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

Certifications

High Speed Non Woven Handle Cubic Bag, Box Bag, Fabric Bag, Non-Plastic Bag/Shopping Bag, Cheap PP Non Woven Bag, Promotional Supermarket Shopping Bag Machine

FAQ

Q:How long will your engineer reach our factory?
A:Within one week after machine arrival your factory.

Q: How many days will you finish installing ?
A:We will finish installation and training within 15days.

Q: What should we charge for your engineer?
A:You should charge for the cost of our engineer's visa , air tickets, hotel, food ,and also their salary 80USD one day per person.

Q: How long is your machine's warranty period?
A:All our machine have one year guarantee, starting from finished installation.

Q: How could we do after one year warranty period?
A:We also can do service for you, but you need pay salary for my technician 80USD/day.

Q:How could we do if the parts broken within warranty?
A:We would express the free replacement parts during the warranty date.

Q: Does your engineer understand English?
A:Our engineer understand a little English. All our engineer have more than five years machine installation experience. In addition, they can use body language to communicate with customer.

Q:Can you help us find any engineer in our location?
A:Of course, we will check and inform you as soon as possible.

Q:How do we solve the machine problem after your engineer leaving?
A:Generally speaking, there will be no problem after finish installing. In case you have any problem. You can contact our sales at any time. Our engineer will take a solution video according your description.

Q: How many worker do we need running those machines?
A:Except Two for bag making machine, flexo printing, slitting, ultrasonic sewing, hydraulic punching machine only need one person for each.


More Details , Kindly contact with me.
